SANOU Lathe Chuck
- SKU
- 786110K11100
- Brand
- SANOU
- Ships from
- Dubai branch
Dhs. 300.00
Per unit, excl. 5% VAT · VAT added at checkout
- Genuine stock, authorised UAE distributor since 1987
- Free delivery on orders over AED 500
- Collection available from our Dubai branch, Al Quoz Industrial Area
- We will confirm your order by phone or WhatsApp before it ships
The SANOU Lathe Chuck is a self-centering scroll chuck used to hold round, hexagonal and square workpieces on manual and semi-CNC lathes for turning, facing and boring. It is a workshop staple for toolroom operators, production machinists and maintenance shops across the UAE, and is stocked and supplied by SAN Tools from our branches in Dubai Al Quoz, Sharjah and Ajman.
Key features
- Self-centering scroll action — all jaws move together via an internal scroll, so a workpiece centres itself as the chuck key is turned, without individually adjusting each jaw.
- Hardened and ground jaws — the jaws are hardened and precision ground for accurate, repeatable centring over repeated clamping cycles.
- K11, K12 and K72 ranges — K11 is the standard 3-jaw scroll chuck, K12 and K72 cover larger and heavier-duty body sizes for bigger lathes and production work.
- Wide size range — body diameters span from 80mm up to 1000mm, covering everything from small bench lathes to heavy-duty production lathes.
- Standard mounting — fits via a standard back plate/adaptor to match your lathe's spindle nose (back plate sold separately unless otherwise noted).
Applications
- Turning, facing and boring round bar, shafts and round castings
- Holding hexagonal and square stock for lathe work
- General toolroom, maintenance and production lathe work
- Manual and semi-CNC lathes in workshops, fabrication shops and machine shops
Specifications
| Attribute | Detail |
|---|---|
| Vendor / brand | SANOU |
| Product type | Lathe Chuck |
| Chuck series | K11 (3-jaw scroll), K12, K72 |
| Body size range | 80mm to 1000mm |
| Mounting | Standard back plate/adaptor (sold separately unless noted) |
| Sizes / variants available | K11-80, K11-100, K11-125, K11-160, K11-200, K11-250, K11-320, K11-400, K11-500, K12-200, K12-250, K12-315, K72-160, K72-200, K72-250, K72-320, K72-400, K72-500, K72-630, K72-800, K72-1000 |
How to choose
- Match chuck size to your lathe's swing and spindle capacity — an oversized chuck can restrict swing over the bed, while an undersized chuck limits workpiece diameter.
- Confirm your spindle nose type (e.g. camlock or threaded) before ordering the back plate/adaptor so the chuck mounts correctly.
- Choose K72 or K12 for heavier, higher-torque work where extra body strength and clamping force are needed over the standard K11 range.
- Check jaw stroke and workpiece diameter against your typical job range so a single chuck covers most of your day-to-day work.
Frequently asked questions
Does the SANOU lathe chuck come with a back plate?
The back plate/adaptor that mates the chuck to your lathe's spindle nose is sold separately unless the listing states otherwise. Let our team know your lathe's spindle nose type and we will confirm the correct back plate.
What is the difference between the K11, K12 and K72 ranges?
K11 is the standard 3-jaw self-centering scroll chuck. K12 and K72 are built for larger diameters and heavier-duty production and turning work, up to 1000mm body size in the K72 range.
Is this available with delivery in the UAE?
Yes. Available from our Dubai, Sharjah and Ajman branches with UAE-wide delivery; request a quote or WhatsApp +971 52 132 7742.
Browse all clamping and holding solutions or request a quote for your SANOU lathe chuck and matching back plate.
